VENUS TRANSIT OF THE SUN: 08 June 2004, Meudon, France

T256x333 f=16671mm 1/60 F/D=65 22/5 17h55m UT T256x169 f=8447mm 1/60 F/D=35.2 10h30m11s UT T256x169 f=8447mm 1/250 F/D=33 12/06 09h33 UT
Pictures were taken with a 25.6cm F/D 4.95 Newtonian:
+ 24cm aperture neutral density 4.8 astrosolar filter (stopped at 170mm for T256x42 + Sensia 400)
+ eyepiece (30, 20, 15 or 7.5mm) + 50mm objective
+ Fuji Sensia 400 ISO. 1/1000 to 1/125 sec. exposure
or + Kodak Gold 200 1/1000 to 1/30
or taken with MTO 1000mm F/D 10 + Astrosolar

Full disk images sequence at F=1000mm (MTO F/11)

all 10 images at once
Kodak Gold 200 05:27:50s UT 1/250 Kodak Gold 200 05:33:58s UT 1/500 Kodak Gold 200 05:42:38s UT 1/500 Fuji Sensia 400 07:17:57s UT 1/1000
Kodak Gold 200 07:25:54s UT 1/250 Kodak Gold 200 08:14:50s UT 1/500 Kodak Gold 200 08:45:34s UT 1/1000 Kodak Gold 200 09:27:58s UT 1/500
Kodak Gold 200 09:53:15s UT 1/500 Kodak Gold 200 10:12:50s UT 1/1000 Kodak Gold 200 10:58:23s UT 1/500

Full disk images sequence at F=2112mm (T256x42)

Fuji Sensia 400 05:33:00s UT 1/1000 F/9 Fuji Sensia 400 05:46:09s UT 1/1000 F/12 Kodak Gold 200 06:17:22s UT 1/500 Fuji Sensia 400 06:54:58s UT 1/1000 F/12
Fuji Sensia 400 07:53:58s UT 1/1000 F/12 Fuji Sensia 400 08:34:30s UT 1/1000 F/12 Kodak Gold 200 09:10:02s UT 1/1000 Fuji Sensia 400 09:37:48s UT 1/1000 F/12
Kodak Gold 200 10:20:32s UT 1/500 Fuji Sensia 400 10:44:48s UT 1/1000 F/12 Fuji Sensia 400 11:03:35s UT 1/1000 F/12

Partial disk images at F=3168mm (T256x63 - half size)

Fuji Sensia 400 06:06:56s UT 1/500 Kodak Gold 200 06:39:26s UT 1/250e Fuji Sensia 400 07:47:16s UT 1/500
Fuji Sensia 400 10:01:27s UT 1/500 Fuji Sensia 400 11:05:20s UT 1/500

Partial disk images at F=4223mm (T256x84 - half size)

Fuji Sensia 400 5:26:47s UT 1/250 Fuji Sensia 400 5:49:41s UT 1/500 Fuji Sensia 400 7:07:07s UT 1/500 Fuji Sensia 400 8:05:28s UT 1/1000
Kodak Gold 200 9:17:23s UT 1/250 Fuji Sensia 400 9:43:22s UT 1/1000 Kodak Gold 200 10:24:32s UT 1/125 Kodak Gold 200 10:25:50s UT 1/250
Fuji Sensia 400 10:51:39s UT 1/1000 Fuji Sensia 400 11:09:11s UT 1/1000 Fuji Sensia 400 11:22:48s UT 1/500

High magnification at F=8447mm (T256x169 - zoom in)

Fuji Sensia 400 5:23:17s UT 1/125 Fuji Sensia 400 5:39:11s UT 1/125 Fuji Sensia 400 5:54:47s UT 1/125 Kodak Gold 200 6:27:36s UT 1/30
Fuji Sensia 400 8:12:28s UT 1/125 Kodak Gold 200 9:21:07s UT 1/60 Kodak Gold 200 9:24:25s UT 1/30 Fuji Sensia 400 9:50:58s UT 1/250
Kodak Gold 200 10:30:11s UT 1/60 Fuji Sensia 400 10:56:33s UT 1/125 Fuji Sensia 400 11:01:36s UT 1/125 Fuji Sensia 400 11:10:58s UT 1/125

Visual observations: Drawings of Venus T256x63, x84 and x169:

Venus entry and sunlight scattering in its atmosphere T256x169:
From upper left to lower right: 5:37:40, 5:38:20, 5:39:40 and 5:39:53 UT

Venus exit and sunlight scattering in its atmosphere (contrasts slightly exagerated: the arcs were fainter than sun's surface, and/or at least very thin (1-2" maxi)). Zenith is down, and South is up slightly to the left, East to the right.
3rd contact at 11:04:27 +- 4sec. (T256x169)
4th contact at 11:23:40 to 11:23:45 UT (T256x169)
N. Biver 13/06/2004
